Warehouse partioning for intralogistics & conveyor technology, modular system ECONFENCE® BASIC LINE ZINC HEIGHT 2000M

Warehouse partioning for intralogistics & conveyor technology, modular system ECONFENCE® BASIC LINE ZINC HEIGHT 2000M

€330.00 *
basic price per running meter: €165.00 *
Quantity Unit price
From 2 €165.00 * ( €196.35 VAT included )
From 20 €157.00 * ( €186.83 VAT included )

Prices plus VAT (free shipping)

Free shipping

Stock items. Ready for dispatch in 48 hours

  • SW10100
  • 1x row post BRP2000-VZ-S01 + 1x grid B20020019-VZ incl. fixing material (= 2 linear metres)
  • The article is supplied without doors, end and corner posts. You will find supplementary articles under "Matching"
FIELD OF APPLICATION: The safety guard system for  warehouse partioning... more
Warehouse partioning for intralogistics & conveyor technology, modular system ECONFENCE® BASIC LINE ZINC HEIGHT 2000M

FIELD OF APPLICATION:

The safety guard system for warehouse partioning ECONFENCE® BASIC LINE ZINK is our bestseller and customer favourite in warehouse logistics, production and materials handling technology. With a tested impact energy of 950 joules, it is not only stable but also very economical to buy. The innovative frameless element design used in all our product lines guarantees maximum flexibility. Subsequent adjustments, grid cuts and notches are done in no time at all. Its galvanised and visually appealing surface finish ensures increased corrosion protection.

INTENDED USE:

the Warehouse partioning system  ECONFENCE® BASIC LINE ZINC is intended to use as a fixed separating distance protection device to protect persons against reaching danger points on machines and systems.

GUARANTEED SAFETY EX WORKS / PRODUCT AND USER BENEFITS:

  • Guaranteed high load capacity - tested impact energy 950 joules (verified by pendulum impact test according to DIN EN ISO 14120)
  • Low ground clearance of the safety fence of 38 mm
  • Element cuts on site possible due to frameless grid construction
  • Simple and fast mounting of the protective device
  • Operating instructions included
  • Delivery with EC Declaration of Conformity and CE marking when ordering a protective fence system
Product type: Modular system
System height: 2000mm
Type of material: Steel
Surface refinement: Galvanizing
TECHNICAL DATA: Product type: Modular system      ... mehr

TECHNICAL DATA:

Product type: Modular system
Scope of delivery: 1x row post + 1x grid (B)1983x(H)2006mm - incl. mounting material (= 2 running meters)
System height: 2000mm
Horizontal wire thickness: 15 x 6 mm flat bar, 5.5 mm round wire
Vertical wire thickness: 3.5 mm round wire
Mesh size: 19 x 190 mm, spot-welded
Weight: Post - 7,0 KG / Grid - 22,3 KG
Material type: Steel
Surface finish: high quality galvanised
Manufacturer: TIEMANN Schutz-Systeme GmbH
Product brand: ECONFENCE®
Product line: BASIC LINE ZINC
Certification: Yes
